Remote control commands
R&S
®
NRPxxP
114User Manual 1179.5760.02 ─ 02
Parameters:
<language> SCPI
*RST: SCPI
SYSTem:LED:COLor <color>
Effective if the system status LED is user-controlled, SYSTem:LED:MODE USER.
Sets the color and the flash code of the system status LED.
Parameters:
<color> Hexadecimal code described as
0x0krrggbb
With
k = 0: steady on; k = 1: slowly flashing; k = 2: fast flashing
rr = red
gg = green
bb = blue
Range: 0x00 to 0x02FFFFFF
*RST: 0x00A0A0A0
Example:
SYST:LED:MODE USER
The system status LED is user-controlled.
SYST:LED:COL #H01a00000
The LED flashes slowly in red.
SYSTem:LED:MODE SENSor
The system status LED is controlled by the power sensor firm-
ware.
SYSTem:LED:MODE <mode>
Sets whether the color of the system status LED is controlled by the power sensor firm-
ware or by the user settings.
For more information, see SYSTem:LED:COLor.
Parameters:
<mode> USER | SENSor
*RST: SENSor
SYSTem:MINPower?
Queries the lower power measurement limit.
This value changes if SENSe<Sensor>:CORRection:SPDevice:STATe is set to
ON. The lower measurement limit refers to the power sensor or to the combination of a
power sensor and the components connected ahead of it.
