Remote control commands
R&S
®
NRPxxP
105User Manual 1179.5760.02 ─ 02
SENSe<Sensor>:TRACe:MEASurement:POWer:PULSe:DROop?
Queries the droop of the pulse. The droop is the difference between leading edge
amplitude, pulse top, and falling edge amplitude, as shown in Figure 8-14. The droop is
expressed in percentage of the pulse top amplitude.
The pulse droop measurement is used to test the stability of the output power of a
device, e.g. an amplifier or a transmitter.
Usage: Query only
SENSe<Sensor>:TRACe:MEASurement:POWer:PULSe:TOP?
Queries the pulse top power level detected by the selected analysis algorithm,
SENSe<Sensor>:TRACe:MEASurement:ALGorithm. This value is used as a refer-
ence (0 %) to determine other parameter values such as the rising or falling thresholds.
Usage:
Query only
SENSe<Sensor>:TRACe:MEASurement:POWer:REFerence?
Queries the power level at reference level. See SENSe<Sensor>:TRACe:
MEASurement:DEFine:DURation:REFerence.
Usage:
Query only
SENSe<Sensor>:TRACe:MEASurement:TRANsition:NEGative:OVERshoot?
Queries the height of the local minimum before a rising edge, divided by the pulse
amplitude:
The search interval begins when the signal falls below the lower reference level set by
SENSe<Sensor>:TRACe:MEASurement:DEFine:TRANsition:LREFerence and
ends half a period thereafter.
Usage:
Query only
SENSe<Sensor>:TRACe:MEASurement:TRANsition:POSitive:OVERshoot?
Queries the height of the local maximum before a falling edge, divided by the pulse
amplitude:
Querying measurement results
