R&S NRP P Series User Manual

Remote control commands
R&S
®
NRPxxP
43User Manual 1179.5760.02 ─ 02
Further information:
●
Chapter 8.5.5, "Configuring the trigger", on page 50
8.5.2.1 Trigger states
The power sensor has trigger states to define the exact start and stop time of a mea-
surement and the sequence of a measurement cycle. The following states are defined:
●
Idle
The power sensor performs no measurement. After powered on, the power sensor
is in the idle state.
●
Waiting for trigger
The power sensor waits for a trigger event that is defined by the trigger source.
When the trigger event occurs, the power sensor enters the measuring state.
●
Measuring
The power sensor is measuring data. It remains in this state during the measure-
ment. When the measurement is completed, it exits this state immediately.
8.5.2.2 Waiting for a trigger event
Before a trigger can be executed, the power sensor has to be set to the waiting for trig-
ger state. Depending on the required number of measurement cycles, you use one of
the following commands:
●
INITiate:CONTinuous
A new measurement cycle is started automatically after the previous one has been
terminated.
●
INITiate[:IMMediate]
The number of measurement cycles is restricted.
If TRIGger:COUNt 1 is set, the command starts a single measurement cycle that
renders one result. Every time you send this command, a new measurement cycle
is started.
Otherwise, as many measurement cycles are performed as determined by the trig-
ger count.
8.5.2.3 Trigger sources
The possible trigger conditions and the execution of a trigger depend on the selected
trigger mode and trigger source.
If the signal power exceeds or falls below a reference level set by the trigger level, the
measurement is started after the defined delay time. Waiting for a trigger event can be
skipped.
Trigger source Description Remote commands to initiate the measurement
"Hold" Triggered by the remote command. TRIGger:IMMediate
"Immediate" Measures immediately, does not wait for trigger
condition.
-
Controlling the measurement
