Rear:
23 Trainer/student socket
24 Battery compartment lid
10. Setting Up the Transmitter
 Inthefurthercourseoftheseinstructions,guresinthetextalwaysrefertotheadjacentgureorthegures
withinthesection.Referencestootherguresareindicatedwiththecorrespondinggurenumber.
a) Inserting the Batteries
For the power supply of the transmitter you will need 4 alkaline
batteries (e.g. Conrad item no. 652507, pack of 4, order 1) of
the size AA/mignon.
Proceed as follows to insert the batteries:
The battery compartment lid (1) is located on the back of the
transmitter. Press the corrugated area (2) and push off the lid
downwards.
Ensure that the polarity is correct when inserting the 4 batteries.
A corresponding note (3) is located on the bottom of the battery
compartment.
Then slide the lid of the battery compartment back on from the
bottom until the locking mechanism engages.
Figure 2
Figure 3
