21. Technical Data

a) Transmitter

Frequency range ..................................2.4 GHz

Number of channels .............................6

Digital encoding ....................................AFHDS / AFHDS2A (Automatic Frequency Hopping Digital System)

Operating voltage .................................6 V/DC via 4 type AA/mignon batteries

Signal output/input ................................PS/2 socket (PPM)

Dimensions (W x H x D) .......................174 x 187 x 80 mm

Weight without batteries .......................400 g

b) Receiver

Frequency range ..................................2.4 GHz

Number of channels .............................6

Connector system .................................Futaba/GraupnerJR

Operating voltage .................................4.5 - 6.5 V/DC

Dimensions (L x W x H) ........................41 x 22 x 7.5 mm

Weight ..................................................7 g
