Table 27: RH850/F1KH-D8 Power supply architecture with mixed supply 5V & 3.3V
Case 2 – Mixed Supply 5V & 3.3V
REG1VCC = 3.3V
EVCC = 5V
BVCC = 5V
A0VREF = 5V
AP0 – Port usable with analog or digital function
P8 – Port usable with analog or digital function
P9 – Port usable with analog or digital function
AP1 – Port usable with analog or digital function
P18 – Port usable with analog or digital function
P19 – Port usable with analog or digital function
Table 28: RH850/F1KH-D8 Power supply architecture with mixed supply 5V & 3.3V
Case 3 – Mixed Supply 5V & 3.3V
REG1VCC = 3.3V
EVCC = 5V
BVCC = 5V
A0VREF = 5V
A1VREF = 3.3V
AP0 – Port usable with analog or digital function
P8 – Port usable with analog or digital function
P9 – Port usable with analog or digital function
AP1 – Port usable with analog or digital function
P18 – Port usable with analog or digital function, analog input
voltage limited to max. 3.3V. When analog input terminal is over 3.3V,
do not include the input into an AD scan group.
P19 – Port usable with analog or digital function, analog input
voltage limited to max. 3.3V. When analog input terminal is over 3.3V,
do not include the input into an AD scan group.
Analog port function limitation applies to P18 and P19
