RH850/F1Kx, RH850/F1K Series Hardware Design Guide
R01AN3841ED0110 Rev. 1.10 Page 55 of 108
August 8, 2019
Table 54: Minimum external components of RH850/F1KM-S1 (100pin)
C13, C14, C16
ESR: max. 40
ESR: max. 40
ESR: max. 40
See Chapter 3.1.1, Main Oscillator for details.
The shown values are for reference only.
It must be ensured (by the schematic/PCB designer) that the voltage levels at the device pins always
remain within the specified range of the electrical characteristics (described in the RH850/F1Kx
hardware user’s manual).
See Chapter 4.2.1, Minimum RESET Circuit for details.
A low level must be applied to FLMD1 in case FLMD0 becomes ‘1’ for external flash programming.
As a minimum value, a direct connection to VSS can be applied. But in case the related port (P10_8) is
switched to output ‘1’, it will damage the port/device.
In case of smaller values than the min. value, the typically connected device (ex. E1 emulator) is not able
to apply a high (‘1’) signal.
See Chapters 8, Development Tool Interface and 9, Test Tool Interface for details.
See Chapters 4.3.2, JP0_4/ DCUTRST , 4.4.1, Recommended Connection of Unused Pins and 8,
Development Tool Interface for details.
The resistor is only required when the JTAG/Nexus interface is used for debugging and depends on the
specification of the 3
rd
party development tool specification. See Chapter 8, Development and Test Tool
Interface for details.
