RH850/F1Kx, RH850/F1K Series Hardware Design Guide
R01AN3841ED0110 Rev. 1.10 Page 47 of 108
August 8, 2019
Table 47: RH850/F1K Power supply architecture with mixed supply 5V & 3.3V
Case 3 – Mixed Supply 5V & 3.3V
EVCC = 5V
A0VREF = 3.3V
AP0 – Port usable with analog or digital function
P8 – Port usable with analog or digital function, analog input
voltage limited to max. 3.3V. When analog input terminal is over 3.3V,
do not include the input into an AD scan group.
P9 – Port usable with analog or digital function, analog input
voltage limited to max. 3.3V. When analog input terminal is over 3.3V,
do not include the input into an AD scan group.
AP1 – Port usable with analog or digital function
P18 – Port usable with analog or digital function
Analog port function limitation applies to P8 and P9
Table 48: RH850/F1K Power supply architecture with mixed supply 5V & 3.3V
Case 4 – Mixed Supply 5V & 3.3V
EVCC = 5V
A0VREF = 3.3V
AP0 – Port usable with analog or digital function
P8 – Port usable with analog or digital function, analog input
voltage limited to max. 3.3V. When analog input terminal is over 3.3V,
do not include the input into an AD scan group.
P9 – Port usable with analog or digital function, analog input
voltage limited to max. 3.3V. When analog input terminal is over 3.3V,
do not include the input into an AD scan group.
AP1 – Port usable with analog or digital function
P18 – Port usable with analog or digital function, analog input
voltage limited to max. 3.3V. When analog input terminal is over 3.3V,
do not include the input into an AD scan group.
Analog port function limitation applies to P8, P9 and P18
Table 49: RH850/F1K Power supply architecture with mixed supply 5V & 3.3V
Case 5, Case 6 – Mixed Supply 5V & 3.3V
EVCC = 3.3V or 5V
A0VREF = don’t care
Common condition REGVCC = EVCC not met
