Table 34: RH850/F1KH-D8 Power supply architecture with mixed supply 5V & 3.3V
Case 9 – Mixed Supply 5V & 3.3V
REG1VCC = 3.3V
EVCC = 5V
BVCC = 3.3V
A0VREF = 3.3V
A1VREF = 3.3V
AP0 – Port usable with analog or digital function
P8 – Port usable with analog or digital function, analog input
voltage limited to max. 3.3V. When analog input terminal is over 3.3V,
do not include the input into an AD scan group.
P9 – Port usable with analog or digital function, analog input
voltage limited to max. 3.3V. When analog input terminal is over 3.3V,
do not include the input into an AD scan group.
AP1 – Port usable with analog or digital function
P18 – Port usable with analog or digital function
P19 – Port usable with analog or digital function
Analog port function limitation applies to P8 and P9
Table 35: RH850/F1KH-D8 Power supply architecture with mixed supply 5V & 3.3V
Case 10 – Mixed Supply 5V & 3.3V
REG1VCC = 3.3V
EVCC = 3.3V
BVCC = don’t care
A0VREF = don’t care
A1VREF = don’t care
Common condition REG0VCC = EVCC not met
Table 36: RH850/F1KH-D8 Power supply architecture with mixed supply 5V & 3.3V
Case 11 – Mixed Supply 5V & 3.3V
REG1VCC = 5V
EVCC = don’t care
BVCC = don’t care
A0VREF = don’t care
A1VREF = don’t care
Common condition of REG1VCC (REG1VCC ≤ 3.6V) not met
