If you enter a number that is greater than the number of ports the RFL 9660 has, the
following error message will appear:
Cannot select port > than maximum number of ports
If you enter a number between one and the maximum number of ports the RFL 9660 has (8,
16, 24, or 32), a port information display similar to the one shown in Figure 5-3 will
appear.
Port # n ( )
Interface -RS232 Call Out -Off
Baud Rate -2400 Call Request -None
Data Bits -8 Call Priority -0
Parity -None Call String -
Stop Bits -1 Remote String -
Port Flow Ctrl -None Port String -
Local Port DTR -On Modem String -
Local Flow Ctrl -On Port Password -
To change type Y: _
Figure 5-3. Typical port information display, showing factory default values
If you want to change any of the entries on the port information display, press the [Y] and
[ENTER] keys. The port information display will reappear, with a list of selections at the
bottom. (See Figure 5-4.) Below the list of selections, your regular prompt will change to a
"PORT n >" prompt, with "n" being the port number you entered.
If you don't want to change any of the settings, press the [N] and [ENTER] keys. Your
regular prompt ("LOCAL>" or "REMOTE>") will reappear.
Each time you make a selection from this list, prompts will appear guiding you through the
change. The selections are listed below, in the order they appear on the list.
