Table 14-10. Replaceable parts, RFL 96 MSM I/O RS-232 Device Port Module
Assembly No. 104420
Circuit Symbol
(Figs. 14-20 & 14-21) Description Part Number
C1-3
C4,6,7,9-11,14,17,25
C5,8,12,13,15,16,
18-24
CR1
JP1,2
RZ1-8
U1-8
U9-24,40,41
U25,27,29,32,34,36
U26,28,30,31,33,35,
37,38,43,44,47
U39,45
U42
U46
U48
U49
Capacitor,tantalum,4.7mF,20%,20V,Kemet T322B475M020AS or equiv.
Capacitor,X7R ceramic,0.1mF,10%,50V,AVX SA305C104KAA or equiv.
Not used.
Light-emitting diode,red,Dialight 550-0102 or equiv.
Shorting bar,single,Molex 90059-0009 or equiv.
Resistor network,five 4.7KW 2% resistors,0.75W total,6-pin SIP,
Bourns 4306R-101-472 or equiv.
MOS quad line driver,14-pin DIP,National Semiconductor DS14C88N or equiv.
Not used.
MOS quad line receiver,14-pin DIP,National Semiconductor DS14C89N or equiv.
MOS tri-state octal buffer,20-pin DIP,National Semiconductor MM74HC244N
or equiv.
MOS 4-bit magnitude comparator,16-pin DIP,
National Semiconductor MM74HC85N or equiv.
MOS quad 2-input NAND gate,14-pin DIP,
National Semiconductor MM74HC00N or equiv.
MOS decoder,3-line to 8-line,16-pin DIP,
National Semiconductor MM74HC138N or equiv.
Linear voltage regulator,+12-volt,3-terminal TO-220 case,
National Semiconductor LM340T-12 or equiv.
Linear voltage regulator,-12-volt,3-terminal plastic package,
National Semiconductor LM320T-12 or equiv.
1007 711
0130 51041
39568
98306
30554
0615 302
0615 303
0615 176
0615 167
0615 159
0615 168
0620 69
0620 121
