RFL Electronics RFL 9660 - Replaceable Parts, DC-Input Power Supply Modules for RFL 9660 Digital Switch

RFL 9660 RFL Electronics Inc.
April 24, 2007 14-21 (973) 334-3100
Table 14-6. Replaceable parts, dc-input power supply modules for RFL 9660 Digital Switch
RFL 9125B 24DCPS (24-Vdc Input) - Assembly No. 103150-1
RFL 9125B 48DCPS (48-Vdc Input) - Assembly No. 103150-2
RFL 9125B 125DCPS (125-Vdc Input) - Assembly No. 103150-3
Circuit Symbol
(Figs. 14-11 thru 14-13) Description Part Number
C1,2
C3,5,7
C4,6
C8
C9
C10
C11,14,31,39,45
C12
C13
C15
C16
C17
C18,38
C19
C20-29
C30,36,42,48
C32,40,46
C33,41,47
C34
C35
C37
C43,49
C44
CAPACITORS
Capacitor,ceramic disc,0.005μF,20%,3kV,Centralab DD30-502 or equiv.
Capacitor,metallized polypropylene,0.47μF,10%,250V,radial leads,
Illinois Capacitor 474MPR250K or equiv.
Capacitor,electrolytic,radial leads, value dependent upon model:
RFL 9125B 24DCPS: 220μF,20%,50V,Illinois Capacitor 227RMR050M or equiv.
RFL 9125B 48DCPS: 33μF,20%,250V,Illinois Capacitor 336RMR250M or equiv.
RFL 9125B 125DCPS: 100μF,20%,100V,Illinois Capacitor 107RMR100M or equiv.
Capacitor,electrolytic,radial leads, value dependent upon model:
RFL 9125B 24DCPS: 470μF,20%,50V,Illinois Capacitor 477RMR050M or equiv.
RFL 9125B 48DCPS: 220μF,20%,100V,Illinois Capacitor 227RMR100M or equiv.
RFL 9125B 125DCPS: 22μF,20%,250V,Illinois Capacitor 226RMR250M or equiv.
Capacitor,metallized polypropylene,0.033μF,10%,400V,radial leads,
Illinois Capacitor 333MPR400K or equiv.
Capacitor,ceramic,0.0022μF,5%,100V,AVX SA301A222JAA or equiv.
Capacitor,X7R ceramic,0.1μF,10%,50V,AVX SA305C104KAA or equiv.
Capacitor,tantalum,4.7μF,10%,35V,Kemet T322C475K035AS or equiv.
Capacitor,polyester,0.012μF,2%,100V,Wesco 32P or equiv.
Capacitor,tantalum,15μF,20%,20V,Kemet T322D156M020AS or equiv.
Capacitor,metallized polycarbonate,0.047μF,2%,200V,Wesco 32MPC or equiv.
Capacitor,X7R ceramic,0.01μF,10%,50V,AVX SA105C103KAA or equiv.
Capacitor,tantalum,1μF,20%,35V,Kemet T322B105M035AS or equiv.
Capacitor,polypropylene,0.0049μF,2%,100V,F-Dyne PPA-11-.0049-100-2 or equiv.
Not used.
Capacitor,electrolytic,470μF,20%,35V,radial leads,
Illinois Capacitor 477RZS035M or equiv.
Capacitor,tantalum,2.2μF,20%,25V,Kemet T322B225M025AS or equiv.
Capacitor,X7R ceramic,0.022μF,10%,50V,AVX SA105C223KAA or equiv.
Capacitor,electrolytic,1000μF,20%,16V,radial leads,
Illinois Capacitor 108RZS016M or equiv.
Capacitor,tantalum,220μF,20%,10V,Kemet T350L227M010AS or equiv.
Capacitor,tantalum,4.7μF,10%,50V,axial leads,Kemet T322D475K050AS or equiv.
Capacitor,tantalum,47μF,10%,20V,radial leads,Kemet T353K476K020AS or equiv.
Capacitor,electrolytic,100μF,20%,63V,radial leads,
Illinois Capacitor 107RZS063M or equiv.
1007 1264
1007 1693
1007 1718
1007 1716
1007 1717
1007 1721
1007 1720
1007 1726
1007 1694
0125 12225
0130 51041
1007 1623
5115 39
1007 716
1007 1196
0130 51031
1007 496
0105 69
1007 1722
1007 645
0130 52231
1007 1723
1007 1684
1007 1727
1007 1715
1007 1696
