RFL Electronics RFL 9660 - Replaceable Parts, Fiber Optic Remote Module Transceiver Board

RFL 9660 RFL Electronics Inc.
April 24, 2007 14-61 (973) 334-3100
Table 14-13. Replaceable parts, fiber optic remote module transceiver board
Assembly No. 104460-1
Circuit Symbol
(Figs. 14-26 &
14-27)
Description Part
Number
C1-3
C4,10-22,24,
28-39
C5,41
C6-8
C9,25
C23
C26
C27
R1,3,6
R2
R4
R5
R7
R8
R9
RZ1
RZ2
RZ3
RZ4
RZ5
RZ6
CRZ1,2
DS1-4,7
DS5
DS6
U1,17
U2
U3
CAPACITORS
Capacitor,ceramic,33pF,5%,200V,AVX SA101A330JAA or equiv.
Capacitor,ceramic,0.1μF,10%,50V,AVX SA305C104KAA or equiv.
Capacitor,ceramic,0.001μF,10%,100V,AVX SA101C102KAA or equiv.
Not used.
Capacitor,tantalum,4.7μF,20%,20V,Kemet T322B475M020AS or equiv.
Capacitor,tantalum,10μF,20%,20V,Kemet T110B106M020AS or equiv.
Capacitor,tantalum,100μF,20%,20V,Kemet T110D107M020AS or equiv.
Capacitor,tantalum,220μF,20%,10V,Kemet T110D227M010AS or equiv.
RESISTORS
Not used.
Resistor,metal film,15.0MΩ,1%,1/4W, Type RN1/4
Resistor,metal film,100KΩ,1%,1/4W, Type RN1/4
Resistor,metal film,2.49KΩ,1%,1/4W, Type RN1/4
Resistor,composition,8.2Ω,5%,1/4W,Allen-Bradley CB Series or equiv.
Resistor,metal film,562Ω,1%,1/4W, Type RN1/4
Resistor,composition,10Ω,5%,1/4W,Allen-Bradley CB Series or equiv.
Resistor network,five 10KΩ 2% resistors,0.75W total,6-pin SIP,Bourns 4306R-101-103 or equiv.
Resistor network,five 330Ω 2% resistors,1.0W total,6-pin SIP,Allen-Bradley 406A-331 or equiv.
Not used.
Resistor network,nine 3.3KΩ 2% resistors,2.7W total,10-pin SIP,Dale MSP10C01332G or equiv.
Resistor network,five 560Ω 2% resistors,1W total,6-pin SIP,Bourns 4306R-101-561 or equiv.
Resistor network,five 150Ω 2% resistors,1W total,6-pin SIP, Bourns 4306R-101-151 or equiv.
SEMICONDUCTORS
Suppressor,array,voltage
Not used.
Light-emitting diode,green,right-angle PC mount,Industrial Devices 5300H5 or equiv.
Light-emitting diode,amber,right-angle PC mount,Hewlett-Packard HLMP-5040 or equiv.
MOS shift register,8-bit,serial in/parallel out,16-pin DIP, National Semiconductor MM74HC164N or
equiv.
MOS 8-bit magnitude comparator,20-pin DIP, National Semiconductor MM74HC688N or equiv.
MOS tri-state octal D-type flip-flop,20-pin DIP, National Semiconductor MM74HC374N or equiv.
0125 23305
0130 51041
0130 11021
1007 711
1007 1610
1007 883
1007 717
0410 1689
0410 1480
0410 1326
1009 971
0410 1264
1009 823
32664
96381
32632
101158
101156
101456
32567
99798
0615 173
0615 183
0615 178
<< table continues on next page >>
