Table 14-9. Replaceable parts, RFL 96 AC/ALARM I/O Ac-Input Power/Alarm I/O Module
RFL 96 AC/ALARM I/O (110Vac) - Assembly No. 104400-1
Circuit Symbol
(Figs. 14-18 & 14-19)
Description
Part Number
C1-4,7-10
C5
C6
CR1,2
F1,2
K1,2
K3
L1-6
L7,8
R1,2
VR1
Capacitor,ceramic disc,0.01uF,20%,3KV,Sprague 30GAS10KJ or equiv.
Capacitor,electrolytic,220uF,20%,35V,Panasonic ECEA1VV221S or equiv.
Capacitor,ceramic,0.1uF,10%,50V,AVX SA305C104KAA or equiv.
Diode,silicon,rectifier,1 Amp,1N4003
Fuse,3AG,slow-blow,1A,250V,Littlefuse 313001 or equiv.
Relay,SPDT,12VDC,PCB MTG
Optical input module,3- to 32-Vdc input A 18 mA,
5-volt logic output @50 mA,Grayhill 70M-IDC5 or equiv.
Inductor,10uH,1.5A,5%,J.W.Miller 4622 or equiv.
Inductor,12uH,4.5A,10%,Caddell-Burns 6880-2 or equiv.
Resistor,wirewound,5KΩ,5%,3.25W,Ohmite 4442 Style 995-3A or equiv.
Suppressor,Varistor,metal-oxide,140 Vrms/180 Vdc,Siemens S10K140 or equiv.
1007 1811
1007 1480
0130 51041
30769
6645
101722
98098
30285
30436
1100 460
101170
