Table 14-5. Replaceable parts, RFL 96 DTE I/O Direct Digital I/O Module
Assembly No. 104455
Circuit Symbol
(Figs. 14-9 & 14-10) Description
Part Number
C1-7,9,10
C11,14
C8,12,13
R1,5,9
R2,3
R4,8,21-27
R6,7,10,11
R12-20
U1-3
U4,5
U6,7
Capacitor,X7R ceramic,0.1μF,10%,50V,AVX SA305C104KAA or equiv.
Capacitor,tantalum,1μF,20%,35V,Kemet T322B105M035AS or equiv.
Not used.
Resistor,metal film,4.99KΩ,1%,1/4W, Type RN1/4
Not used.
Resistor,metal film,10KΩ,1%,1/4W, Type RN1/4
Resistor,metal film,1KΩ,1%,1/4W, Type RN1/4
Resistor,metal film,6.98KΩ,1%,1/4W, Type RN1/4
MOS quad line receiver,14-pin DIP,National Semiconductor DS14C89N or equiv.
MOS quad line driver,14-pin DIP,National Semiconductor DS14C88N or equiv.
MOS dual-port RAM,1K x 16/2K x 8, 68-lead chip carrier,
VSLI Technology VT16DP8-70QC or equiv.
0130 51041
1007 496
0410 1355
0410 1384
0410 1288
0410 1369
0615 303
0615 302
0620 320
