Table 8-2. DIP switch settings for modem port setup.
Speed
Parity
Word
Length
No. Of
Stop
Bits
S3-1
S3-2
S3-3
S3-4
S3-5
S3-6
S3-7
19,200 None 8 bits 1 ON ON OFF ON ON ON ON
Table 8-3. DIP switch settings for direct digital port setup
Speed
Parity
Word
Length
No. Of
Stop
Bits
S3-1
S3-2
S3-3
S3-4
S3-5
S3-6
S3-7
300 Odd 7 bits 1 OFF ON OFF OFF ON OFF ON
2 OFF ON OFF OFF ON OFF OFF
8 bits 1 OFF ON OFF OFF ON ON ON
2 OFF ON OFF OFF ON ON OFF
Even 7 bits 1 OFF ON OFF OFF OFF OFF ON
2 OFF ON OFF OFF OFF OFF OFF
8 bits 1 OFF ON OFF OFF OFF ON ON
2 OFF ON OFF OFF OFF ON OFF
None 7 bits 1 OFF ON OFF ON ON OFF ON
2 OFF ON OFF ON ON OFF OFF
8 bits 1 OFF ON OFF ON ON ON ON
2 OFF ON OFF ON ON ON OFF
1200 Odd 7 bits 1 OFF ON ON OFF ON OFF ON
2 OFF ON ON OFF ON OFF OFF
8 bits 1 OFF ON ON OFF ON ON ON
2 OFF ON ON OFF ON ON OFF
Even 7 bits 1 OFF ON ON OFF OFF OFF ON
2 OFF ON ON OFF OFF OFF OFF
8 bits 1 OFF ON ON OFF OFF ON ON
2 OFF ON ON OFF OFF ON OFF
None 7 bits 1 OFF ON ON ON ON OFF ON
2 OFF ON ON ON ON OFF OFF
8 bits 1 OFF ON ON ON ON ON ON
2 OFF ON ON ON ON ON OFF
2400 Odd 7 bits 1 ON ON ON OFF ON OFF ON
2 ON ON ON OFF ON OFF OFF
8 bits 1 ON ON ON OFF ON ON ON
2 ON ON ON OFF ON ON OFF
Even 7 bits 1 ON ON ON OFF OFF OFF ON
2 ON ON ON OFF OFF OFF OFF
8 bits 1 ON ON ON OFF OFF ON ON
2 ON ON ON OFF OFF ON OFF
None 7 bits 1 ON ON ON ON ON OFF ON
2 ON ON ON ON ON OFF OFF
8 bits 1 ON ON ON ON ON ON ON
2 ON ON ON ON ON ON OFF
<< table continues on next page >>
