RFL Electronics RFL 9660 - Typical Port Summary Table

(site ID)
# TYPE LABEL MODE DTR RTS CallBack
RFL 9660 RFL Electronics Inc.
April 24, 2007 4-24 (973) 334-3100
1 RS232 SEL 221F - Line 21 0 0 0 N
2 RS232 OPTIMHO - Line 15 0 0 0 N
3 RS232 DLP - Line 17 0 0 0 N
4 RS232 DFR 3 4 0 0 Y
5 RS232 QUANTUM 0 0 0 N
6 RS232 0 0 0 N
7 RS232 0 0 0 N
8 RS232 0 0 0 N
REMOTE> _
Figure 4-24. Typical port summary table
11. Once the RFL 9660 has connected you to the device you want, run its application software program to
test or poll the device.
Refer to the documentation supplied with the software for information on how to do
this.
12. When you are finished, exit the application software program.
Refer to the documentation supplied with the software for information on how to do
this.
13. Type in the port deselect code ("BYE") to terminate the connection to the device.
The RFL 9660 will return a "REMOTE>" prompt to your display when the device port is
deselected.
14. Repeat steps 8 through 13 if you want to connect to another device. If you are finished, terminate the
session by pressing the [Q] and [ENTER] keys.
The RFL 9660 will disconnect your terminal and end the session. The following
message will appear on your display:
User terminated this session!
The RFL 9660 will begin its hang-up sequence. When it is finished, the RFL 9660 will be
ready to start another session.
