RFL Electronics RFL 9660 - DIP Switch Settings for Fiber Optic Remote Module Addressing

RFL 9660 RFL Electronics Inc.
April 24, 2007 2-14 (973) 334-3100
Table 2-1. DIP switch settings for fiber optic remote module addressing
Port Number
S1-1 S1-2 S1-3 S1-4 S1-5
1
OFF OFF OFF OFF OFF
2
ON OFF OFF OFF OFF
3
OFF ON OFF OFF OFF
4
ON ON OFF OFF OFF
5
OFF OFF ON OFF OFF
6
ON OFF ON OFF OFF
7
OFF ON ON OFF OFF
8
ON ON ON OFF OFF
9
OFF OFF OFF ON OFF
10
ON OFF OFF ON OFF
11
OFF ON OFF ON OFF
12
ON ON OFF ON OFF
13
OFF OFF ON ON OFF
14
ON OFF ON ON OFF
15
OFF ON ON ON OFF
16
ON ON ON ON OFF
17
OFF OFF OFF OFF ON
18
ON OFF OFF OFF ON
19
OFF ON OFF OFF ON
20
ON ON OFF OFF ON
21
OFF OFF ON OFF ON
22
ON OFF ON OFF ON
23
OFF ON ON OFF ON
24
ON ON ON OFF ON
25
OFF OFF OFF ON ON
26
ON OFF OFF ON ON
27
OFF ON OFF ON ON
28
ON ON OFF ON ON
29
OFF OFF ON ON ON
30
ON OFF ON ON ON
31
OFF ON ON ON ON
32
ON ON ON ON ON
