3. To change any of the entries on the port information display, press the [Y] and [ENTER] keys.
The port information display will reappear, with a list of selections at the bottom. (See
Figure 3-9.) Below the list of selections, the "LOCAL>" prompt will change to a
"PORT n >" prompt, with "n" being the number of the port you selected during step 2.
Each time you change one of the port configuration settings, this screen will be re-
displayed with the change you made entered on it. To correct a change, simply make
the change again.
If you don't want to change any of the settings, press the [N] and [ENTER] keys. The
"LOCAL>" prompt will reappear and you will no longer be in the port configuration
mode.
Port # n ( )
Interface -RS232 Call Out -Off
Baud Rate -2400 Call Request -None
Data Bits -8 Call Priority -0
Parity -None Call String -
Stop Bits -1 Remote String -
Port Flow Ctrl -None Port String -
Local Port DTR -On Modem String -
Local Flow Ctrl -On Port Password -
To change type Y: _
a -Label port b -Call request
c -Call out d -Password
e -Call string f -Modem string
g -Remote string h -Port string
i -Port priority j -Local port DTR
k -Local flow ctrl (XON/XOFF) l -Port flow ctrl
m -Communications params q -Quit
PORT n > _
Figure 3-9. Typical port information display with list of selections for changing port information
