The configuration commands are listed below, in the order they appear on the configuration
command list. They are also listed in Table 5-1, along with their meaning, setting range, and
default setting. Space is provided in Table 5-1 for you to write in the value you want to assign to
each configuration command. If you do this before you start calling up configuration commands, it
will simplify programming.
NOTE
Many of the configuration commands listed in Table 5-1 have factory default settings. These
settings should be satisfactory for most applications. Under normal circumstances, you should
only have to change these settings if your application requires longer or shorter delay periods.
Table 5-1. Configuration setting worksheet, RFL 9660 Digital Switch
Command Meaning Setting Range Default Setting Actual Setting
PP nn Period awaiting password 5 to 99 seconds 28 seconds
PA nn Silence before deselect code 1 to 99 seconds 1 second
PB nn Silence after deselect code 1 to 99 seconds 1 second
PT nnnn Inactive period, port selected 20 to 32000 seconds 600 seconds
PM nnnn Inactive period, menu mode 20 to 32000 seconds 600 seconds
CC xxx Port deselect code Up to 3 characters BYE
CR x... Modem reset code 2 to 30 characters . . .
CB n x... Call back string 1 to 40 characters . . .
PW 1 x... Front-end password #1 2 to 7 characters . . .
PW 2 x... Front-end password #2 2 to 7 characters . . .
PW 3 x... Front-end password #3
(reserved for super-user)
2 to 7 characters . . .
PW 4 x... Front-end password #4 2 to 7 characters . . .
PW 5 x... Front-end password #5 2 to 7 characters . . .
PW 6 x... Front-end password #6 2 to 7 characters . . .
PW 7 x... Front-end password #7 2 to 7 characters . . .
PW 8 x... Front-end password #8 2 to 7 characters . . .
PW 9 x... Front-end password #9 2 to 7 characters . . .
PW 10 x... Front-end password #10 2 to 7 characters . . .
CM x Message format LONG, BRIEF, or NONE LONG
EC x Enable CCITT modem sequence Y (yes) or N (no) N
PE x Password enable Y (yes) or N (no N
EP x Enable port selection by number Y (yes) or N (no) Y
RFL 9660 RFL Electronics Inc.
August 18, 1998 5-13 (973) 334-3100
