U - UPDATE HARDWARE CONFIGURATION
The "U" command tells the RFL 9660 to update the hardware configuration
information in its memory. This command is automatically run every time the
RFL 9660 is turned on. You will have to execute the "U" command any time fiber optic
remotes are added to the fiber optic ring with the RFL 9660 turned on.
Format:LOCAL> U [ENTER]
The following message will appear while the RFL 9660's memory is being updated:
FOM detected
Please wait...
When the RFL 9660's memory has been updated, the port configuration will be
displayed. A typical port configuration display appears in Figure 5-7.
1 RS232 2 RS232 3 RS232 4 RS232
5 RS232 6 RS232 7 RS232 8 RS232
9 RS232 10 RS232 11 RS232 12 RS232
13 RS232 14 RS232 15 RS232 16 RS232
17 Fiber 18 Fiber 19 Fiber 20 Fiber
21 Fiber 22 Fiber 23 Fiber 24 Fiber
25 None 26 None 27 None 28 None
29 None 30 None 31 None 32 None
LOCAL> _
Figure 5-7. Typical port configuration display
RFL 9660 RFL Electronics Inc.
August 18, 1998 5-22 (973) 334-3100
