RFL Electronics RFL 9660 - Page 129

RFL 9660 RFL Electronics Inc.
April 24, 2007 8-4 (973) 334-3100
Table 8-3. DIP switch settings for direct digital port setup - continued.
Speed Parity
Word
Length
No. Of
Stop
Bits S3-1 S3-2 S3-3 S3-4 S3-5 S3-6 S3-7
4800 Odd 7 bits 1 ON OFF ON OFF ON OFF ON
2 ON OFF ON OFF ON OFF OFF
8 bits 1 ON OFF ON OFF ON ON ON
2 ON OFF ON OFF ON ON OFF
Even 7 bits 1 ON OFF ON OFF OFF OFF ON
2 ON OFF ON OFF OFF OFF OFF
8 bits 1 ON OFF ON OFF OFF ON ON
2 ON OFF ON OFF OFF ON OFF
None 7 bits 1 ON OFF ON ON ON OFF ON
2 ON OFF ON ON ON OFF OFF
8 bits 1 ON OFF ON ON ON ON ON
2 ON OFF ON ON ON ON OFF
9600 Odd 7 bits 1 OFF OFF ON OFF ON OFF ON
2 OFF OFF ON OFF ON OFF OFF
8 bits 1 OFF OFF ON OFF ON ON ON
2 OFF OFF ON OFF ON ON OFF
Even 7 bits 1 OFF OFF ON OFF OFF OFF ON
2 OFF OFF ON OFF OFF OFF OFF
8 bits 1 OFF OFF ON OFF OFF ON ON
2 OFF OFF ON OFF OFF ON OFF
None 7 bits 1 OFF OFF ON ON ON OFF ON
2 OFF OFF ON ON ON OFF OFF
8 bits 1 OFF OFF ON ON ON ON ON
2 OFF OFF ON ON ON ON OFF
19,200 Odd 7 bits 1 ON ON OFF OFF ON OFF ON
2 ON ON OFF OFF ON OFF OFF
8 bits 1 ON ON OFF OFF ON ON ON
2 ON ON OFF OFF ON ON OFF
Even 7 bits 1 ON ON OFF OFF OFF OFF ON
2 ON ON OFF OFF OFF OFF OFF
8 bits 1 ON ON OFF OFF OFF ON ON
2 ON ON OFF OFF OFF ON OFF
None 7 bits 1 ON ON OFF ON ON OFF ON
2 ON ON OFF ON ON OFF OFF
8 bits 1 ON ON OFF ON ON ON ON
2 ON ON OFF ON ON ON OFF
