Table 14-1. Replaceable parts, RFL 96 CPU Central Processor (CPU) Module - continued.
Circuit Symbol
(Figs. 14-1 & 14-2) Description Part Number
J1
J2-J4
S1
S2
S3
Y1
. . .
MISCELLANEOUS COMPONENTS
Not field-replaceable.
Shorting bar,single,Molex 90059-0009 or equiv.
Switch array,four SPST piano switches,8-pin DIP,AMP 1-435802-5 or equiv.
Switch,SPDT,momentary snap-action pushbutton,
C & K Components 8125A (Termination Option A) or equiv.
Switch array,8-position,16-pin DIP,AMP 5-435166-3 or equiv.
Crystal,quartz,11.0592 MHz
Shorting bar,single,Molex 90059-0009 or equiv.
98306
101122
49583
38933
99215 10
98306
