# TYPE LABEL MODE DTR RTS CallBack
RFL 9660 RFL Electronics Inc.
April 24, 2007 4-31 (973) 334-3100
1 RS232 SEL 221F - Line 21 0 0 0 N
2 RS232 OPTIMHO - Line 15 0 0 0 N
3 RS232 DLP - Line 17 0 0 0 N
4 RS232 DFR 3 4 0 0 Y
5 RS232 QUANTUM 0 0 0 N
6 RS232 0 0 0 N
7 RS232 0 0 0 N
8 RS232 0 0 0 N
REMOTE> _
Figure 4-29. Typical port summary table
The following information appears in the port summary table:
# Port number (1 to 32). As more device port modules are added to the RFL 9660, more
lines will appear on this table, one for each installed port.
TYPE Type of connection ("RS232" for RS-232, or "FO" for fiber optic).
LABEL The name assigned to the port by the super-user. This is an optional field that may
contain up to 30 ASCII characters.
NOTE
Port labels are case-sensitive. If the port label was entered as all CAPITALS, you will have to enter
it that way for the RFL 9660 to accept it.
MODE Request connect method assigned to this port:
0 Port Callout not enabled.
1 RTS + DTR
2 DTR + RTS
3 RTS
4 DTR
9 Disabled by the switch. This means that a device timeout occurred and the RFL 9660
disabled the callout feature for that port. When this happens, the super-user will have
to use the "P" command to manually reset the port callout feature. (See Section 5.)
