Fax Unit (D545)
SM 5 D545
Fax option
Type C5501
D545
8. Install the speaker [A] to the controller box (
x 2) and connect the speaker cable [B] with
the speaker relay cable [C] (
x 3).
9. Connect the two modular harnesses [A] (TEL), [B] (LINE1) to the modular bracket [C].
10. Connect the two modular harnesses [A] (TEL), [B] (LINE1) to the FCU.
To Next Page
