Ricoh Aficio MP201SPF Service Manual

Fusing
D115/D116 4-20 SM
4.5.7 CHECKING THE NIP BAND
You can check the nip band to see if the fusing unit is in a good condition–especially, if the hot
roller and pressure roller are correctly installed.
1. Activate the SP mode.
2. Select SP1-109-001.
3. Specify "1."
4. Press the OK key.
5. Press the
key. The copy mode is activated.
6. Place an OHP sheet on the by-pass tray.
7. Press the
key. The copier feeds the OHP sheet, and stops it between the hot roller and
the pressure roller for about 20 seconds.
8. Wait until the OHP sheet is output.
9. Press the
key.
10. Make sure SP1-109-001 is selected.
11. Specify "0".
12. Press the OK key.
13. Quit the SP mode.
You see an opaque stripe on the OHP sheet. This is the trace of the nip band. The normal nip
band is symmetrical on the OHP sheet. Both ends are slightly thicker than the center.
 There are no specifications or standards for the nip band of this copier.

Ricoh Aficio MP201SPF Specifications

General

Type	Multifunction Printer
Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Max Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Fax Transmission Speed	3 seconds per page
Modem Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Dimensions	485 x 450 x 481 mm
Warm-up Time	30 seconds
Paper Output Capacity	100 sheets
Print Speed	20 ppm
Copy Speed	20 cpm
Scanner Type	Flatbed
Zoom	25% - 400%
Supported Paper Sizes	A4, A5, A6, B5, Legal, Letter
Operating System Compatibility	Windows, Mac, Linux
Duplex Printing	Automatic
