Controller Options
D115/D116 2-32 SM
2.8.2 WIRELESS LAN (IEEE 802.11A/G) INSTALLATION
Unplug the machine power cord before starting the following procedure.
Accessories
Check the accessories and their quantities against the table below.
No. Description Q’ty
1 Wireless Adapter 1
2 Wireless LAN Card 1
3 LAN Card Cover 4
4 Caution Sheet 1
5 Label 1
Installation Procedure
1. Remove the interface cover [A] (
x 2).
2. Install the Wireless adaptor into I/F slot [B] (
x 2).
3. Install the Wireless LAN card in the wireless adaptor.
4. Attach the antenna cap to the wireless LAN card.
5. Turn on the main power switch.
6. Print out the configuration page (User Tools/Counter > Printer Features > List/Test Print),
