Ricoh Aficio MP201SPF - Df Feed Motor; Df Transport Motor

ARDF
D115/D116 4-58 SM
4.13.8 DF FEED MOTOR
1. DF rear cover ( p.4-53)
2. Inner cover [A] (
x 1)
3. DF feed motor with bracket [B] (
x 2, x 4, x 3, timing belt)
4. DF feed motor [C] (
x 2)
4.13.9 DF TRANSPORT MOTOR
1. DF rear cover ( p.4-53)
2. DF feed motor (
p.4-58)
3. DF transport motor with bracket [A] ( x 2, spring x 1, timing belt)
4. DF transport motor [B] (
x 2)
