Ricoh Aficio MP201SPF Service Manual

Guidance for Those Who are Familiar with Predecessor Products
SM 1-13 D115/D116
Product
Information
1.4 GUIDANCE FOR THOSE WHO ARE FAMILIAR WITH
PREDECESSOR PRODUCTS
The D115/D116 range of machines is the successor model to the D068/D069 range of
machines. If you have experience with the predecessor line, the following information may be of
help when you read this manual.
Differences from Predecessor Products
D115/D116 D068/D069
Security Card (HDD
Encryption and Data
Overwrite Security Unit)
Standard only for D115 Option only for D069
Copying Speed
20 cpm: Memory copy
16 cpm: ADF 1 to 1
17cpm: Memory copy
16cpm: ADF 1 to 1
 The following parts are unique for D115/D116. When replacing the following parts, use
the parts specified for each model. DO NOT mix up the following parts for
D067/D068/D069/D072 and D115/D116. Otherwise, both of the machine operation and
output quality are not guaranteed.
1. BICU with Controller Unit
 If wrong part is installed, an image is not correctly copied on outputs with the DF one to
one copy.
2. Laser Unit (Writing Unit)
 If wrong part is installed, a copied image might be too dark or light on outputs.
3. Polygon Scanner Motor (A part of Laser Unit)
 If wrong part is installed, a copied image might be too dark or light on outputs or an SC
might be issued.
4. Model Name Plate
5. Mechanical Counter (S-C4: Assembled, S-C4.5: Service optional part)

Ricoh Aficio MP201SPF Specifications

General

Type	Multifunction Printer
Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Max Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Fax Transmission Speed	3 seconds per page
Modem Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Dimensions	485 x 450 x 481 mm
Warm-up Time	30 seconds
Paper Output Capacity	100 sheets
Print Speed	20 ppm
Copy Speed	20 cpm
Scanner Type	Flatbed
Zoom	25% - 400%
Supported Paper Sizes	A4, A5, A6, B5, Legal, Letter
Operating System Compatibility	Windows, Mac, Linux
Duplex Printing	Automatic
