USB 2.0/SD Slot Type B
SM 2-27 D115/D116
Installation
17. Attach the decal [A] to the USB2.0/SD Slot as shown above.
When Installing the Handset
1. Do steps 1 to 8 in “installation procedure”.
2. Make two holes the upper left cover with a screwdriver as shown above.
Smooth the holes in the upper left cover.
3. Attach the handset bracket [A] (
x 2)
4. Attach the cradle [B] to the handset bracket (
x 2)
To Next Page
