Ricoh SP C260SFNw - Control Panel

No. Name Description
1 Print Cartridge Install the print cartridges from the machine rear, in the order of
cyan (C), magenta (M), yellow (Y), and black (K). Messages
appear on the screen when print cartridges need to be replaced,
or new ones need to be prepared.
2 Fusing Unit Lever Lower both the left and right levers when you print on an
envelope.
3 Fusing Unit Fuses toner to the paper.
You might have to move this unit to check for or remove jammed
paper.
4 Waste Toner Bottle Collects toner that is wasted during printing.
5 Transfer unit You need to remove this when you replace the waste toner bottle.
• For details about the messages that appear on the screen when consumables need to be replaced,
see page 343 "Error and Status Messages on the Screen".
Control Panel
DUE128
1 2 3 4576
9
8 10
No. Name Description
1 NFC tag Connects a smart device to the machine when you touch this tag
on a smart device.
1. Guide to the Machine
22
