Ricoh SP C260SFNw - Exterior: Rear View

Exterior: Rear View
DUE204
3
1
2
4
5
6
8
7
9
No. Name Description
1 G3 (analog) Line Interface Connector For connecting a telephone line.
2 External Telephone Connector For connecting an external telephone.
3 Ethernet Port For connecting the machine to the network
using a network interface cable.
4 USB Port For connecting the machine to a computer
using a USB cable.
5 Stop Fences Pull up this fence to prevent paper falling off
when printing a large amount of paper at a
time.
The fence can be adjusted at the A4/Letter
or Legal size position.
6 Cable Cover Remove this cover when connecting cables
to the machine.
7 Rear Cover Remove this cover when loading paper
longer than A4 in Tray 1.
Guide to Components
19
