3. Using both hands, carefully push up the front cover until it closes.
When closing the front cover, push the upper area of the cover firmly. After closing the cover,
check that the error is cleared.
• Do not pull out the paper tray (Tray 1).
• If paper is jammed in Tray 2 but is difficult to locate, pull out Tray 2 to remove it. After removing the
paper, carefully push Tray 2 all the way back inside the machine.
If paper jams inside the transfer unit
If paper jams inside the transfer unit, follow the procedure below to remove it.
1. Pull the front cover open lever and then carefully lower the front cover.
10. Troubleshooting
360
