The Ethernet module has a factory setting IP（192.168.0.250）and network mask（255.255.255.0）. Users
can process as shown in Figure 4.3 to check whether the Ethernet module and PC in the same network
segment. If in the same network segment, then congratulations to you, and you do not have to read the
following network setting contents. If it is different, then the following settings is very important to you.
Figure 4.3
Above contents is used to tell you how to make the user’s PC with the Ethernet module in the same
network segment.
How to configure Ethernet module built-in ELC-22DC-DA-R-N IP address?
Start Ethernet module IP address configuration software.
Step one: Double click the file “DeviceManager” in CD and then the following contents will pop out:
