367
A.2 Technical data: xLogic (PR&ELC series)
Standard CPU Units
(PR-6 series)
PR-6AC-R
PR-6DC-DA-R
Power supply:
Nominal voltage
AC110V-240V
DC 12-24V
Operating limits
AC85 - 265 V
DC 10.8-28.8V
Immunity from micro
power cuts
---
Typ.5 ms
Max. Startup current
---
Max. 0.25A
Max. absorbed power
34 mA (85V AC)
26 mA (265V AC)
1.1 W (10.8V dc) ; 1.2W (28.8V dc)
Protection against polarity
inversions
Yes
Yes
The main frequency range
47-63Hz
---
Input parameters:
Input No
4 ( I1-I4 )
4 ( I1-I4 )
Digital input
4 ( I1-I4 )
4 ( I1-I4 )
Analogue input
None
4 ( I1-I4)(0..10V DC)
Input voltage
AC0-240V
DC0-28.8V
Input signal0
AC0-40V；<0.03mA
< 5V DC;<0.1mA
Input signal1
AC79-240V； >0.06mA
> 8 V DC;>0.3mA
Input current
---
0.4mA @ 10.8V dc
0.5mA @ 12.0 V dc
1.2mA @ 24 V dc
1.5mA @ 28.8 V dc
Input Response Time
Delay time at 0 to 1：
120V AC ：Typ. 50 ms
240V AC ：Typ. 30 ms
Delay time at 1 to 0：
120V AC ：Typ. 90 ms
240V AC ：Typ.100 ms
Delay time at 0 to 1 ：
Typ. 1.5 ms ；
Delay time at 1 to 0 ：
Typ. 1.5 ms
Maximum counting
frequency
Typ. 4Hz
Typ.：4 HZ
Sensor type
Contact or 3-wire PNP
Contact or 3-wire PNP
Isolation between power
supply and inputs
None
Resistive
Isolation between inputs
None
None
Protection against polarity
inversions
Yes
None
Inputs used as analog inputs( I1-I4 )
Measurement range
---
DC 0---10V
Input impedance
---
Min, 24KΩ ; Max. 72KΩ
Input voltage
---
28.8 V DC max
