381
Program and settings
Backup
10 Years
Data Power-off retentivity
Yes
Weight
Approx.500g
Short-circuit protection
External fuse required
Cycle time
typ. 0.6ms ➞ 8.0ms
Connection cables
2 x 1.5 mm² or 1 x 2.5 mm²
Ambient temperature
-20 to + 55 ºC
Storage temperature
–40 ºC to + 70 ºC
Certification
CE
Mounting
On 35 mm standard mounting rail, 4 MW, or wall-mounting
Dimensions
W x H x D (133*90*61 mm)
Programming cable
PC cable, (RS232 or USB)
Third party device(HMI)
<=> xLogic
Yes (work as modbus master or slave)
Extensions
Yes(Can connect up to 16 pcs PR-E extensions.)
High speed input
No
I9---IC(60kHz)
HMI
Yes
RS485 port
Option1:Can use PRO-RS485 cable to convert program port to RS485 port
Option2:Or use PR-RS485 extension module
Option3:built-in RS485 port is available
Extension Units
(PR-E-16 series)
PR-E-16AC-R
PR-E-16DC-DA-R
PR-E-16DC-DA-TN
Power supply:
Nominal voltage
AC110V-240V
DC 12-24V
Operating limits
AC85 - 265 V
DC 10.8-28.8V
Immunity from micro
power cuts
---
Typ. 5 ms
Max. Startup current
---
Max. 0.25A
Max. absorbed power
53mA (85V ac) ;
38mA (265V ac)
3.5 W (10.8V dc) ;
4.5 W (28.8V dc)
Protection against polarity
inversions
Yes
Yes
The main frequency range
47-63Hz
---
Input parameters:
Input No
8 ( I1-I8 )
8 (I1-I8 )
Digital input
8 ( I1-I8 )
8 (I1-I8 )
Analogue input
None
4 ( I1-I4)(0..10V DC)
Input voltage
AC0-240V
DC 0-28.8V
