380
Cable length
---
10 m max. shielded and twisted
Current Inputs(0/4..20mA)
Input No
----
2 ( I5-I6 )
Measurement range
----
0/4...20mA
Resolution
----
10bit ,0.02mA
Accuracy at 25 °C
0.05mA
Output parameters:
Output No.
10 (Q1-QA)
6 (Q1-Q6) Relay
+2(Q7-Q8)Transistor(PNP)
+2AQ
Output type
Relay output
Continuous current
Resistive load 10A/Inductive load 2A (Relay)
Resistive load
10A/Inductive load 2A
(Relay)
0.3A(Transistor)
Max. breaking voltage
AC 250 V /DC 110 V(Relay)
AC 250 V /DC 110
V(Relay)
DC 30V(Transistor)
Max. Allowable Power Force
1250VA /300W(Relay)
1250VA /300W(Relay)
9W(Transistor)
Electrical durability
Expectancy
10
5
Operations at Rated Resistive Load(Relay)
---
Mechanical life
10
7
Operations at No Load condition(Relay)
---
Response time
Operate Time : 15 mSec. Max.(Relay)
Release Time : 10 mSec. Max.(Relay)
Operate Time : <1 ms
Release Time : <1 ms
Built-in protections
Against short-circuits: None
Against overvoltages and overloads: None
Analog Output
Signal type
None
1(0...10V)+1(0...20mA)
Resolution
None
0.01V 、0.02mA
Accuracy at 25 °C
None
0.02V、0.05mA
Switch frequency:
Mechanism
10Hz
---
Resistor/light load
2Hz
10HZ
Sensitive load
0.5Hz
0.5HZ
PWM frequency
---
10K HZ(Q7,Q8 must have
same frequency when PWM
works)
PWM accuracy at 500Hz
---
< 0.5% (20 % ➞ 80 %)
load at 10 mA
Other parameters:
Function blocks
1024 blocks
RTC accuracy :
MAX ±2S/day
RTC Backup at 25 °C
20 days
