388
channel and power supply
Cable length
---
10 m max. shielded and twisted
Output parameters:
Output No.
4 (Q1-Q4)
Output type
Relay output
Continuous current
Resistive load 10A/Inductive load 2A (Relay)
Max. breaking voltage
AC 250 V /DC 110 V(Relay)
Max. Allowable Power Force
1250VA /300W(Relay)
Electrical durability
Expectancy
10
5
Operations at Rated Resistive Load(Relay)
Mechanical life
10
7
Operations at No Load condition(Relay)
---
Response time
Operate Time : 15 mSec. Max.(Relay)
Release Time : 10 mSec. Max.(Relay)
Built-in protections
Against short-circuits: None
Against overvoltages and overloads: None
Switch frequency:
Mechanism
10Hz
Resistor/light load
2Hz
Sensitive load
0.5Hz
Other parameters:
Weight
Approx.250g
Connection cables
2 x 1.5 mm² or 1 x 2.5 mm²
Ambient temperature
-20 to + 55 ºC
Storage temperature
–40 ºC to + 70 ºC
Certification
CE
Mounting
On 35 mm standard mounting rail, 4 MW, or wall-mounting
Dimensions
W x H x D (48*90*64 mm)
Extension Units for
Ethernet CPU(ELC-12-N)
(EXM-E series)
EXM-E-AI-I
EXM-E-PT100
EXM-E-AQ-V
EXM-E-AQ-I
Power supply:
Nominal voltage
DC 12-24V
DC 24V
DC 12-24V
Operating limits
DC 10.8-28.8V
DC 15-28.8V
DC 10.8-28.8V
Immunity from micro
power cuts
Typ. 5 ms
Max. Startup current
Max. 0.25A
Max. absorbed power
3.5 W (10.8V dc) ; 4.5 W (28.8V dc)
Protection against polarity
inversions
Yes
Input parameters:
Input No
4 ( I1-I4 )
2 PT100
---
Digital input
None
None
---
