389
Analogue input
I1-I4(0/4...20mA)
2PT100
---
Analog inputs
Measurement range
0/4...20mA
-50℃--200℃
---
Resolution
0.02mA
0.5℃
---
Accuracy at 25 °C
Max. 0.05mA
< 1 ℃
---
Isolation between analog
channel and power supply
None
None
Cable length
10 m max. shielded and twisted
Output parameters:
Output No.
---
2(AQ1-AQ2)
Output type
---
0...10V
0...20mA
Resolution
---
0.01V
0.02mA
Accuracy at 25 °C
---
0.02V
0.05mA
Other parameters:
Weight
Approx.250g
Short-circuit protection
External fuse required
Connection cables
2 x 1.5 mm² or 1 x 2.5 mm²
Ambient temperature
-20 to + 55 ºC
Storage temperature
–40 ºC to + 70 ºC
Certification
CE
Mounting
On 35 mm standard mounting rail, 4 MW, or wall-mounting
Dimensions
W x H x D (48*90*64 mm)
RS485 communication module
for ELC-12-N Ethernet CPU
(EXM-E-RS485)
EXM-E-RS485
Power supply:
Nominal voltage
DC 12-24V
Operating limits
DC 10.8-28.8V
Immunity from micro power cuts
Typ. 5 ms
Max. Startup current
Max. 0.1A
Max. absorbed power
1.5 W (10.8V dc) ; 1.8W W (28.8V dc)
Protection against polarity inversions
Yes
Input parameters:
None
Output parameters:
None
Other parameters:
Weight
Approx.250g
Short-circuit protection
External fuse required
Connection cables
2 x 1.5 mm² or 1 x 2.5 mm²
Ambient temperature
-20 to + 55 ºC
