Data Line

Select a data line (D1, D2, D3, or D4) you wish to configure. The data line label is lit

after selected. You can configure the trigger settings for the four data lines

respectively.

Trigger Input On/Off

Tap the

TrigIn on/off button to enable or disable the respective trigger input settings

for the selected data line.

Source Under Control

In the

Channel item, you can select one or more of CH1, CH2, and CH3 as the source

under control by ticking the box.

Trigger Type

Tap the TrigType drop-down button to select to trigger on the rising edge, falling

edge, high level, or low level of the input signal.

TIP

For the input signal, high level ranges from 2.5 V to 3.3 V, low level from 0 V to 0.8 V, and the

noise tolerance is 0.4 V.

Output Response

Tap the Response drop-down menu to set the trigger response type to "OutOn",

"OutOff”, or “OutFlip”.

• OutOn: Turns on the output of the channel currently selected as the source

under control when the trigger condition is met.

• OutOff: Turns off the output of the channel currently selected as the source

under control when the trigger condition is met.

• OutFlip: Toggles the channel output state. That is, turns off the channel when the

current channel is on, or turns on the channel when the current channel is off.

11.2 Trigger Output

The specified data line outputs a high/low level signal when the control source turns

on the output.

Tap > Trigger and select Trigger Output to access the trigger output setting

interface, as shown in the figure below.

Trigger

DP2000 User Guide
