12
Store and Recall
You can store various types of files in internal or external memory, and recall the
stored files when required. Besides, you can also copy, paste, or delete files of the
specified type in internal or external memory.
This series power supply provides an internal non-volatile memory and two USB
HOST interfaces (one on the front panel and the other on the rear panel), which can
used to connect USB storage devices for external storage. The internal memory is C
disk, and the external memory is D disk and E disk.
TIP
The instrument only supports the flash memory USB storage device of FAT32 format.
Press the front-panel or tap > Store to enter the interface as shown in the
figure below.
Figure 12.1 Disk Interface
•
C Disk
Folders cannot be stored in C disk. The file types available for storage include
state file (.RSF), log file (.ROF), Arb file (.RTF), bitmap file (.BMP), calibration file
(.CLF), and option installation verification file (.LIC).
TIP
- Do not copy unsupported file type to C disk, or a prompt message “Filetype not
supported.” will be displayed.
- The C disk supports file locking. You can lock/unlock files via the SCPI
command :MEMory:LOCK <name>,<bool>. A lock icon will appear at the upper-
Store and Recall
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
DP2000 User Guide
59
