• IP Configuration

The TCP/IP address information for the instrument can be obtained in different

ways, including DHCP, Auto IP, and Manual IP. You can tap the DHCP, AUTO, or

MANUAL on/off switch to enable or disable the configuration. When ON is

selected, the corresponding configuration mode is enabled. When OFF is

selected, the corresponding configuration mode is disabled.

- DHCP: The Dynamic Host Configuration Protocol (DHCP) can automatically

assign a dynamic IP address to the instrument from a DHCP server. By

default, the instrument is configured to use DHCP.

- Auto IP: When “AUTO” is “ON”, it obtains the IP address (169.254.0.1

to 169.254.255.254) and subnet mask (255.255.0.0) depending on the

current network configuration.

- Manual IP: When “MANUAL” is “ON”, you need to set the network

parameters (such as IP address) manually.

TIP

- When all the three configuration modes are set to "ON", the priority of parameter

configuration is "DHCP", "Auto IP", and "Manual IP". Therefore, to set the address

manually, DHCP and Auto IP should be set to "OFF".

- They cannot be "OFF” at the same time.

• IP Address

Contact your network administrator for a valid IP address and set the address

manually. The format of the IP address is nnn.nnn.nnn.nnn; wherein, the first nnn

ranges from 1 to 223 (excluding127), and the other three range from 0 to 255.

Enter the desired IP address using the front-panel parameter input area or the

virtual keypad. This setting is non-volatile. The instrument will load your IP

address automatically at the next power-on if “DHCP” and “Auto IP” are set

to "OFF".

• Gateway

Contact your network administrator for a valid gateway address and set the

default gateway manually. The format of the address is nnn.nnn.nnn.nnn;

wherein, the first nnn ranges from 1 to 223 (excluding 127), and the other three

range from 0 to 255.

Enter the desired gateway address using the front-panel parameter input area or

the virtual keypad. This setting is non-volatile. The instrument will load your

gateway address automatically at the next power-on if “DHCP” and “Auto

IP” are set to "OFF".

• Subnet Mask
