ROBOT S6
E32 - STRETCH DRIVER
OVERTEMP.
- STRETCH DRIVER
SHORT CIRCUIT.
- STRETCH DRIVER
UNDERVOLT.
- STRETCH HEAT
SINK OVERTEMP.
- STRETCH CURRENT
LIMIT.
Alarm at the film
stretching motor.
A failure
occurred to the
film stretching
motor.
Check the motor
and refer to the
wiring diagram.
E33 - PRESTRETCH
DRIVER OVERTEMP.
- PRESTRETCH
DRIVER SHORT
CIRCUIT.
- PRESTRETCH
DRIVER UNDERVOLT.
- PRESTRETCH HEAT
SINK OVERTEMP.
- PRESTRETCH
CURRENT LIMIT.
Alarm at the film
pre-stretching
motor.
A failure
occurred to the
film
pre-stretching
motor.
Check the motor
and refer to the
wiring diagram.
E35 - TRACTION
OVERCURRENT.
Overcurrent alarm
at the driving
motor.
The motor has
been working
heavily for an
exceedingly long
period.
Check the motor
operation, ensure
the machine is
free to move and
refer to the
relevant electric
diagram.
E36 - CARR.
OVERCURRENT.
Overcurrent alarm
at the carriage
motor.
The motor has
been working
heavily for an
exceedingly long
period.
Check the motor
operation, ensure
the carriage is
free to move and
refer to the
relevant electric
diagram.
E60 - ALL. BROKEN
FILM.
Film end/breakage
alarm.
The film has
broken or reel is
empty.
Insert the film
or replace reel.
E61 - ALL. COUNTER
CORNER.
Inductive
malfunction
alarm.
Inductive sensor
malfunction.
Check the
conditions of the
inductive sensor.
E62 - ALL. ENCODER
CARR.
Spool carriage
lifting encoder
alarm.
Spool carriage
lifting encoder
malfunction.
Check the
operation of the
motor and/or
sensor and refer
to the relevant
electric diagram.
E65 - ALL. CREASING
BLOCKED
creasing device
alarm locked.
The motor has
been working
heavily for an
exceedingly long
period.
Check the
functioning of
the motor,
assuring that the
creasing device
is free to move
and consult the
wiring diagram.
