Wrist Camera Instruction Manual

Along with your kit you will have the calibration board used for UR3 robots on one side the the board, part number

ACC-CALIB-BOARD. The color balance circles are not used yet with the vision system and are for future use. If you loose or

damage your board, you can print the following file:

Info

UR3 calibration board must be printed on Letter (8.5'' x 11'') or A4 paper, make sure scale is at 100%. You can

validate that your calibration board had the good scale by measuring the scale on your sheet.
