Wrist Camera Instruction Manual
5.2.1.5. Validate Model
Tip
At any moment during the teaching process, the user can access contextual help videos with the Play button.
The Validate Model step will start right after the fourth picture is taken at the end of the Refine Model step.
Info
If the object is properly detected, it will display green and red outlines.
If the object has not been recognized, please refer to the Guidelines on Object Teaching section for instructions.
Accept button
Retake button
The Validate Model step is used to verify the contour selection of the model. If satisfactory, the user can accept the model
by pressing the Accept button, or go through the Refine Model step again by tapping the Retake button.
Main points to observe:
l Object contours and detected features are outlined in green
l Features from the model that cannot be located on the object in the field of view of the camera are outlined in red.
©Robotiq inc. 2016-2018
62
