Wrist Camera Instruction Manual
4.3. Copy a Calibration
When defining a snapshot position, it is possible to copy the calibration from another snapshot position. This allows for a
faster snapshot position modification when using the same work plane.
Work Plane
To ensure proper precision, the work plane surface of both (new and copied) snapshot positions should be the
same.
To copy a calibration, you need to have a snapshot position already defined from which you want to copy the calibration.
l Create a new Snapshot feature point on the same plane as the existing Snapshot point you want to copy.
l Move the robot to this position.
l Go to the Installation tab, select Camera from the menu on the left and tap the Snapshot tab
l Choose the new Snapshop position.
l Select the existing Snapshot position you want to copy and select Copy.
l In the Wizard, select Save This Position.
l The calibration from the previously selected snapshot position will be used for this new one.
©Robotiq inc. 2016-2018
38
