Rockwell Automation Publication 1715-UM001J-EN-P - December 2020 103

Chapter 2 Installation Instructions

5. Record the MAC addresses.

The MAC addresses are between slot 0 and 1 of the adapter base. Every

hardware component has its own unique MAC address. This hardware

address is affixed to the hardware on a label.

6. Place the new module on to the dowel pin on the adapter base unit.

Unlocked Position

32084 M

32077-M

32077 M

Connect To Dowel Pins

Default Chapter3
