36 Rockwell Automation Publication 1715-UM001J-EN-P - December 2020
Chapter 2 Installation Instructions
Before You Begin This section lists important information that you must consider before
starting to build your 1715 Redundant I/O System:
• Review the parts list and identify the system components.
• Review the power requirements for the system and for field devices.
• Review design considerations for heating and cooling.
• Specify an enclosure.
• Install the necessary software.
Ensure that Warranty is Not Compromised
Graphical Representation
Parts List
These parts are available to build a 1715 Redundant I/O System. Their
description and catalog part numbers are as follows.
ATTENTION: Failing to install retaining clips and properly secure the
Terminal Assembly (TA) can lead to connector / pin damage on the
modules and the 1715-A3IO. Failure to comply with this Attention Notice
will render the Warranty void and the equipment will not be covered.
IMPORTANT
Throughout this manual, some graphics do not depict the actual
hardware as required. These graphics are for representational
purposes only and do not necessarily reflect the actual
component layout of your system.
Table 4 - Parts Table
Cat. No. Description
1715-AENTR Adapter
1715-IB16D 16-channel digital input module
1715-OB8DE 8-channel digital output module
1715-IF16 16-channel analog input module
1715-OF8I 8-channel analog output module
1715-A2A 2-slot adapter base unit
1715-A3IO 3-slot I/O base unit
1715-TASIB16D Termination assembly - digital input simplex
1715-TADIB16D Termination assembly - digital input duplex
1715-TASOB8DE Termination assembly - digital output simplex
1715-TADOB8DE Termination assembly - digital output duplex
1715-TASIF16 Termination assembly - analog input simplex
1715-TADIF16 Termination assembly - analog input duplex
1715-TASOF8 Termination assembly - analog output simplex
1715-TADOF8 Termination assembly - analog output duplex
1715-N2T Tall slot filler cover
1715-N2S Short slot filler cover
1715-C2 Expansion cable - 2 m
