258 Rockwell Automation Publication 1715-UM001J-EN-P - December 2020

Appendix B 1715-IB16D Digital Input Module Diagnostics

Figure 75 - Threshold Settings

Threshold Diagnostics Settings

There are three types of threshold diagnostics settings to choose from in the

Logix Designer application:

• Full Diagnostics Configuration

• None Diagnostics Configuration

• Custom Diagnostics Configuration

Short

Circuit

Indeterminate

Off

Open

Wire

Default Chapter3
