44 Rockwell Automation Publication 1715-UM001J-EN-P - December 2020

Chapter 2 Installation Instructions

I/O Termination Assemblies

I/O termination assemblies are inserted into the I/O base units. There are

eight types of termination assemblies (two for each module) depending on the

architecture of your system and the I/O modules you are going to use.

32059 M

Table 5 - I/O Termination Assembly Descriptions

I/O Module Termination Assembly Cat. No. Termination Assembly Description

1715-IB16D

1715-TASIB16D Digital input simplex

1715-TADIB16D Digital input duplex

1715-OB8DE

1715-TAS0B8DE Digital output simplex

1715-TADOB8DE Digital output duplex
